European Standard IPE AA Beam (Super Lightweight I-Section)

Ruicheng Steel supplies high-quality IPE AA Beams, also known as “Super Lightweight European I-Beams.”

The IPE AA series features the same height and flange width dimensions as the standard IPE but with thinner webs and flanges. This engineering adjustment results in a significantly lighter section weight. It is the ideal solution for engineering projects where weight saving is a priority or where loads are moderate. By choosing IPE AA, customers can achieve substantial cost savings on both steel tonnage and logistics while maintaining compliance with European structural standards.

Material Grades:

• Structural Carbon Steel: S235JR, S235J0 (EN 10025-2)

• High Tensile Steel: S275JR, S355JR, S355J2 (EN 10025-2)

Executive Standards:

• Dimensions: Manufacturer Standard based on DIN 1025-5 (IPE AA series)

• Tolerances: EN 10034

• Surface Condition: EN 10163-3

Manufacturing Technique: Hot Rolled

Size Specifications (IPE AA Series):

• Height (h): 80mm – 600mm (Matches standard IPE height)

• Flange Width (b): 46mm – 220mm (Matches standard IPE width)

• Web Thickness (s): Thinner than standard IPE (e.g., IPE AA 200 web is approx 3.2mm vs 5.6mm for standard IPE)

• Weight Advantage: Approximately 20-30% lighter than standard IPE beams.

Length Options: 6m, 12m, or cut-to-length based on container size (5.8m / 11.8m)

Surface Treatment: Black (Bare), Shop Primer (Red/Grey), Hot Dip Galvanized

Processing Services: Cutting, Punching, Shot Blasting, Painting

Main Applications: Light steel structures, Purlins, Lintels, Exhibition stands, Greenhouses, Cable trays
