Hot Rolled Steel H Beam (Wide Flange Structural Steel)

Ruicheng Steel provides a comprehensive range of Hot rolled steel H beam (also known as Universal Beams or Wide Flange Beams). Unlike standard I-beams, H-beams feature wider flanges and consistent thickness throughout the flange, offering a more efficient cross-section for structural loads.

Our H-beams are produced using advanced hot-rolling technology, ensuring uniform internal structure and high dimensional accuracy. They are the preferred structural material for high-rise buildings, large-span factories, and heavy machinery, offering a high strength-to-weight ratio that reduces overall construction steel usage by 15-20%.

Classification (Series):

• HW (Wide Flange): Flange width is roughly equal to height (e.g., 200×200). Best for columns.

• HM (Middle Flange): Flange width is roughly 2/3 of height (e.g., 300×200).

• HN (Narrow Flange): Flange width is roughly 1/3 to 1/2 of height (e.g., 400×150). Best for beams.

Executive Standards:

• China: GB/T 11263-2010, GB/T 700

• Japan: JIS G3101, JIS G3192

• USA: ASTM A36, ASTM A572, ASTM A992

• Europe: EN 10025, EN 10034

Material Grades:

• Mild Steel: Q235B, SS400, S235JR, A36

• High Strength Steel: Q345B, Q355B, S355JR, S355J2, A572 Gr.50

Size Specifications:

• Height (H): 100mm – 900mm

• Flange Width (B): 50mm – 400mm

• Web Thickness (t1): 5mm – 30mm

• Flange Thickness (t2): 7mm – 40mm

Length Options: Standard 6m, 9m, 12m. Custom cut-to-length services (e.g., 11.8m) available upon request.

Surface Treatment: Black (Bare), Oiled, Shop Primer Painted, Hot Dip Galvanized.

Processing Services: Welding, Bending, Punching, Cutting.

Main Applications: Steel structure columns, Bridge components, Industrial workshop frames, Pile foundations, Railway construction.
