Premium PPGI & PPGL Steel Coil (Color Coated Steel) – RAL Colors & Custom Patterns
-
Dual Base Options: Available in both PPGI (Galvanized base for cost-efficiency) and PPGL (Galvalume base for superior corrosion resistance).
-
Infinite Color Choices: Full support for RAL Color matching and custom patterns (wood grain, brick, camouflage) to suit your architectural design.
-
High-Performance Coatings: Offers various paint systems including PE, SMP, HDP, and PVDF to guarantee 15-20+ years of color retention and weatherability.
-
Precision Coating Technology: Uniform paint thickness control (Top: 15-25μm / Back: 5-10μm) ensures excellent finish and rust protection.
-
Surface Protection: Optional protective film application to prevent scratches during transportation and installation.
products details
Ruicheng Steel is your premier source for high-quality Color Coated Steel Coils, including both PPGI (Pre-painted Galvanized Iron) and PPGL (Pre-painted Galvalume). These products combine the structural strength of steel with the aesthetic appeal and durability of advanced coating systems. They are the preferred material for modern roofing, wall cladding, and interior decoration.
| Pre-Painted Galvanized Steel Coil | |
|---|---|
| Technical Standard | EN10147/EN10142/DIN 17162/JIS G3302/ASTM A653 |
| Steel Grade | Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490, |
| SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ | |
| CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer's Requirement | |
| Type | Coil/Sheet/Plate/Strip |
| Thickness | 0.126.0mm or customer's requirement |
| Width | 6001500mm according to customer's requirement |
| Coil Weight | 4-27mt |
| Type of Coating | Hot Dipped Galvanized Steel(HDGI) |
| Zinc Coating | AZ30-AZ160, Z50-Z140g/m2 |
| Surface treatment | Top paint: PVDF, HDP, SMP, PE, PU |
| Prime paint: polyurethane, epoxy, PE | |
| Back paint: epoxy, modified polyester |
| PPGL Coil | |
|---|---|
| Base Metal | Al-Zn Coated Steel (Galvalume) |
| Coating Composition | 55% Aluminum, 43.5% Zinc, 1.5% Silicon |
| Thickness | 0.15 mm – 1.5 mm |
| Width | 600 mm – 1500 mm |
| Coil Weight | 3 – 8 tons |
| Al-Zn Coating | AZ30 – AZ150 g/m² |
| Top Coating Thickness | 10–30 μm |
| Back Coating Thickness | 5–20 μm |
| Paint Type | PE, SMP, PVDF |
| Surface Options | Glossy, Matte, Embossed, Printed |
| Standard | ASTM A755, JIS G3322, EN 10169 |
